FRAME PARTS

for PENTON / KTM motorcycles

Brake Rod / Pipe Mount / Footpegs / Tool Bag & Rack

Steering Races / Fork Bumpers / Shocks / Number Plates



Call: Al Buehner - (216) 651-6559   Mon-Fri    8:30am to 4pm E.S.T.

or e-mail us a list of your quantities and part numbers pentonpartsusa@sbcglobal.net



     (NOTE: parts are available only while supplies last - prices subject to change without notice)

  BRAKE ROD PARTS for all straight hub 1972-73 175cc Penton motorcycles

A



B





















              C                   D                                                 E                           F         G             E                             H                I



A- # 6-1-000            reproduction brake rod for 1968-71 bikes (20" long)  -  Sold out

B - #51-03-070-000  reproduction brake rod for 1972-75 bikes (21.5" long) - Sold out

C - #6-9-000            adjustment wing nut for brake rods  -  $5 each
D - #32-03-073-000  pressure spring for brake rods (6.5mm I.D. x 108mm L) -  $3 each
E - #51-03-066-100  R/S outer nylon bushing  -    $8 each
F -
#51-03-067-000  nylon bushing f/spring  -       Sold out
G -
#51-03-062-000  chrome return spring  -        $4 each
H -
#51-03-061-100   L/S outer nylon bushing  -   $8 each                               made in USA

I - #51-03-063-044  actuating arm  -                   $12 each

NOS BRAKE RODs for 1973-79 bikes with conicle rear hub

A

B



A - #54-03-070-000  plated brake rod for 1973-75 bikes (25" 637mm long) -  $48 each

                        fits the #54-03-160-100  brake pedal



B - #55-03-070-000  plated brake rod for 1979 bikes (25" 637mm long) -    $48 each

                         fits the #55-03-060-000/ 100 & #55-03-060-500 brake pedals

                               NOTE: some rust and corrosion on brake rods from age

 Reproduction BRAKE ROD Parts for 1973-75 bikes with conicle rear hub

      A                           B         made in USA                        C             C

A - # 6-9-000 -  adjustment wing nut for brake rods           $5 each
B - #32-03-073-000 -  pressure spring for brake rods
(6.5mm I.D. x 108mm L)    $3 each
C - #31-03-061-000 -  nylon brake pedal bushing             $8 each


  used Brake Pedal

 for 1973-75 conicle hub bikes 175/ 250/ 400



#54-03-160-USED -     VGC   $58 each

   chrome blistered with surface rust, may also be bent



   Brake Pedal Spring

 for 1973-75 conicle hub bikes 175/ 250/ 400



#54-03-062-000 -  spring       $6 each

   fits the #54-162-100 brake pedal



A



B

C

D

E

 Alloy Brake Pedal

 for 1977-78 MC-5 and GS-6 bikes 125/ 175/ 250/ 400



A - #55-03-060-000 -  short pedal       $36 each

      #55-03-060-USED short pedal         $20 each

B - #55-03-062-000 -  long spring       sold out

C - #55-03-060-100 -  short pedal       $35 each

D - #55-03-062-100 -  short spring       $7 each

E - #55-03-061-000 -  bronze bushing      $3 each







A

B

C

 Alloy Brake Pedal

 for 1979-80 MC-80 and GS-80 bikes 125/ 175/ 250/ 400 / 420



A - #55-03-060-500 -   pedal assy      $60 each



B - #55-03-065-000 -   spring for end    sold out

C - #55-03-066-000 -   pedal end      sold out

also available - #55-03-061-000 bronze bushing   $3 each

                    made in USA

Reproduction  Side Stand

 for 1973-74 CMF frames

#51-03-023-300 -       sold out
       unpainted, 15" long, includes spring



#31-03-021-000 - extra spring   $11 each

        stainless steel spring for side stand

Rubber pipe mount assembly



#51-05-062-000 -       $9 each
       complete with washers, self lock nut, and bolt




A



B







                  C        D

Reproduction Stainless Steel

Gripper FOOT PEGS



New style with serrated top to grip boots

A - #51-03-040-200 -         Sold out
            Foot peg, left side
B - #51-03-140-200 -         Sold out
             Foot peg, right side
C - #0985-080-003 -           $ .20 each
             nylock nut for bolt
D - #0931-080-403 -           $ .65 each
              mounting bolt                        made in USA

  Reproduction

  Swing Arm Bushings

for all 175 CMF frames 1972-1973 having cush drive sprocket



 - #51-03-031-000 -         $22 each

Reproduction

Swing Arm Bolt

Fits all 1972-1980 bikes. Redesigned cap that is extra long and slotted to fit 12mm open end wrench for installing and removing.

 - #51-03-033-000 -         $70 each

Reproduction
Stainless Steel SKID PLATE

Fits all 1972-75 CMF frames. Thicker, heavy duty construction will resist bending.

#51-03-012-000 -            Sold out          made in USA

A

B

C

   Used Alloy Brackets

           may have some dirt and wear marks

A - #52-03-145-000 -   used       $12 each
            232mm eye to eye -w/ counter sink hole
B - #54-09-042-400 -   used       $12 each
             205mm eye to eye - front brake anchor
C - #54-03-045-200 -   used        $ 12 each
             190mm eye to eye -w/ counter sink hole

New reproduction
TOOL BAG RACK
for 1972-76 PENTON motorcycles


#51-11-059-000 -             Sold out
        Tool bag rack for CMF frames,
         painted silver grey
made in USA

New reproduction
LEATHER TOOL BAG
for PENTON motorcycles - fits Tool Bag Rack

                                               made in USA

#51-11-060-000 -            $82 each
     approximate size 8-1/4" wide x 6" deep x 5" high

          A                  B                  C

New reproduction
Steering Head Race kit

#51-01-086-044  -  only $46 each
           includes: 2 inner races, 2 outer races,

                     34 balls, & 2 viton O-rings


also available separately:
A- #51-01-083-000  -           $12 each

           inner race (for steering head)

     43mm O.D. x 26.5mm I.D. x 5.25mm thick
B- #51-01-085-000         -    $12 each

           outer race (for fork plate & bushing)

     43mm O.D. x 26.5mm I.D. x 5.25mm thick
C- #2-52-100  -                     $2 each

            Viton O-ring

New reproduction Fork Bumpers
for all Penton motorcycles.



# 51-03-090-000 -            $8 each

                        made in USA

Reproduction Rubber Buttons



Fit into frame holes to cushion the gas tanks

 - #51-07-069-100-        $4.00 each



A



B

C



D

RUBBER WASHERS

used under steel washers throughout bike to protect

plastic and painted parts



A  #51-05-082-100  -           $ .20 each

        rubber washer         $9.00 per pk/50



B  #0021-060-000-P -           $ .20 each

         flat washers         $3.00 per pk/50



C  #0985-060-003-P -           $ .20 each

      6mm  nylock nuts     $4.00 pk/50



D  #0933-060-203-P  -         $ .25 each

      6 x 20mm bolts        $4.00 pk/25

REAR SHOCKS

13 E to E shock for show bikes or easy riding.

      Not for off-road or competition use.



#51-04-010-200 -            Only $90 pair
         Includes 4 bolts, nuts, and bushings.


 Head Light Plastic Number Plates

size - aprox. 9" (230mm) x 11" (280mm)

   all have raised rounded edge on front side

#55-01-090-500   Yellow -      $8 each


#55-01-090-600    White -       $8 each



Plastic Oval Number Plates

size - aprox. 9" (230mm) x 11" (280mm)

   all have raised rounded edge on front side

#55-01-090-100   Yellow -      $5 each   or

                           3 for $13
#55-01-090-200    White -       $5 each
or

                           3 for $13

#55-01-090-300    Green -       $5 each   or

                          3 for  $13

#55-01-090-400    Red -       $5 each   or

                          3 for  $13

#55-01-090-500    Black -       $5 each   or

                          3 for  $13

Plastic Rectangular Number Plates

 small size - aprox. 10"  x 7-1/4"



   #55-01-090-021   Yellow -      $5 each   or

                                3 for $13

   #55-01-090-023    Green -       $5 each   or

                               3 for $13

   #55-01-090-024    Red -       $5 each   or

                               3 for $13

   #55-01-090-025    Black -     $5 each   or

                               3 for $13

Plastic Rectangular Number Plates

 large size - aprox. 12"  x 10"



   #55-01-090-031   Yellow -      $7 each   or

                                3 for $18

   #55-01-090-032    white -       $7 each   or

                               3 for $18

   #55-01-090-033    Green -       $7 each   or

                               3 for $18

MC5 Mud Flap

Rubber mud flap fits 1976 and 77 Penton and KTM MC5 bikes
attaches to frame and Falk inner fender
#55-08-021-000 -       $15 each
